Braeburn 1020NC Non-Programmable Thermostat – 1H/1C, 24V or Battery Powered

Overview

The Braeburn 1020NC is a compact, non-programmable thermostat designed for straightforward comfort control. Its dimensions (3.62 in. high x 4.72 in. wide x 1.38 in. deep) fit standard junction boxes, and it can be powered by either 24V AC or two AA alkaline batteries, offering installation flexibility tailored to your setup.

With a bright blue backlit display, the unit makes temperature reading effortless in any lighting. A separate sub-base supports easier wiring and mounting, while non-volatile memory preserves your preferences between sessions. A front reset button provides a quick way to return to default settings when needed.

Key features

• Large 2 sq. in. display with bright blue backlight, adjustable temperature limits, hardwire or battery power
• Permanent memory retains settings, compressor short cycle protection, separate O & B terminals
• Low battery indication, ESD guard electronics, front access reset button
• F˚/C˚ switch, gas/electric fan switch
• English/Spanish packaging and instruction card with free contractor branding

Environment and range

The thermostat supports a broad comfort range from 45°F to 90°F (7°C to 32°C) with an accuracy of ±1°F (±0.5°C). It performs well across a wide humidity spectrum from 5% to 95% relative humidity.

Compatibility and practical use

Designed for versatility, it works with single-stage gas, oil, or electric heating or cooling systems, including single-stage heat pumps, and even millivolt heating systems (250 mV–750 mV). This makes it a flexible option for many homes and retrofit projects where simple, reliable control is valued.

What you gain

• Reliability without programming complexity, ideal for renters or minimalist setups
• Clear visibility and quick adjustments in living spaces, bedrooms, or hallways
• Flexible mounting and straightforward installation via the included sub-base
