Evergreen 6205E GE X-13 Furnace Blower Motor Replacement – 1/2 HP, 230V

Effortless X-13 replacement for furnace blowers

The Evergreen EM X-13 Direct Replacement Motors are designed to swap into many existing X13 style constant torque systems without any programming. This 1/2 HP, 208-230 V unit fits residential and light commercial applications where a compact, ready-to-install motor is desired. The fully encapsulated, one‑piece construction keeps the profile low and simplifies mounting in tight spaces, making upgrades or replacements smoother for service professionals and informed homeowners alike. A rotation sensing system supports both CW and CCW orientations, helping to ensure reliable operation across diverse duct designs.

Why it fits your HVAC setup

This motor is crafted to replace direct-drive blower motors used in furnaces, air handlers, and packaged systems originally designed for a 6-pole 1075 rpm PSC motor. It is intended as a versatile drop-in solution that minimizes downtime and avoids complex reconfigurations on most common 1/2 HP X13 installations.

Key benefits at a glance

• Direct drop-in replacement for many X13 constant torque motors, with no programming required
• Four discrete speeds via 24 VAC, plus an automatic continuous fan speed option
• Five discrete speeds available using 24 VAC (three using 18 VDC) for flexible airflow control
• Fully encapsulated, one-piece design with a lower profile for easier installation
• NEMA 48-frame mounting (5.6 inch diameter) with a 5-inch long, 1/2 inch shaft
• Bi-directional CW/CCW rotation sensing technology for reliable operation
• UL and CSA recognized component for quality assurance

What to know about compatibility and installation

Designed to replace direct-drive blower motors in residential and light commercial systems that previously used a 6-pole PSC motor, this unit is a universal X13 replacement for many major manufacturers. It replaces or supersedes a long list of model numbers across brands, helping to simplify part sourcing when upgrading older equipment. It is important to note that this motor does not replace certain ECM models such as EON, 3.0, 2.3, or 2.5 variants.

Specifications at a glance

• Horsepower: 1/2 HP
• Voltage: 208-230 V
• Frame: NEMA 48
• Shaft length: 5 inches
• Rotation: CW/CCW with sensing
• Speed options: multiple (4 with 24 VAC, automatic continuous, and 5 via 24 VAC/18 VDC options)

Whether you are performing routine maintenance or upgrading an aging HVAC setup, this Evergreen X-13 motor offers a practical balance of compatibility, ease of installation, and flexible control. Use it to improve airflow, reduce vibration, and restore consistent performance across a range of duct configurations. While the design supports a wide array of installations, always verify model compatibility with your specific furnace or air handler before replacing the motor.

Note

For best results, confirm that your system’s control wiring matches the 24 VAC (and optional 18 VDC) speed control scheme and that the mounting footprint aligns with the NEMA 48 frame. If you are unsure about compatibility, consult a qualified HVAC technician.
