Southwire Romex SIMpull NM-B 10 Gauge 3-Conductor Cable, 100 ft, Pink

Overview

Southwire Romex SIMpull NM-B cable is designed for residential wiring needs, delivering a dependable, nonmetallic option for branch circuits. This 10 gauge 3 conductor with ground cable comes in a bright pink jacket and is suitable for normally dry locations at temperatures not to exceed 90 C. While its insulation can handle higher temperatures, ampacity follows the 60 C conductor rating rules for most residential installations, aligning with standard electrical codes.

Key advantages

• Coated in a patented SIMpull Cable Jacket that makes pulling, stripping, and installation easier, even in tight spaces.
• Primarily used for residential branch circuits powering outlets, switches, and other loads, offering a straightforward wiring choice.
• UL Listed type NM-B, ensuring compliance with recognized safety standards for nonmetallic sheathed cable.
• 10 gauge, 3 conductors with ground, supplied in a 100 ft coil for extended runs and fewer joins.
• Made in America, reflecting domestic manufacturing lineage.

Usage scenarios and installation notes

This NM-B cable is suitable for exposed and concealed work in normally dry locations. It can be run in air voids of masonry block or tile walls where the area is not wet or damp. It is rated for up to 600 volts, making it a common choice for residential branch circuits and lighting circuits in typical home wiring projects.

Specifications at a glance

• Voltage rating: 600 volts
• Temperature rating: up to 90 C insulation, ampacity aligned with 60 C conductor limits
• Length: 100 feet per coil
• Conductor count: 3 with ground
• Jacket: SIMpull coated for easy pulling and installation

Practical considerations

When planning a project, consider the dry location requirement and the local electrical code provisions. The bright pink jacket helps identify the cable quickly on job sites, while the compact coil size reduces the number of splices needed for longer runs. This combination supports a clean, organized wiring process without claiming guaranteed outcomes.
